ROTARY
JOINT
WATER
ROTARY
UNION
|
UNIVERSAL |
CONTINUOUS CASTING |
IN THE SHAFT MOUNTING |
HIGH PRESSURE
HIGH SPEED |
|
Max. Pressure: 750 psi
Max. Temperature: 350 °F
Max Speed: 3500 RPM
Size: 1/4" - 2"
# of passages:
1 - 2 |
|
Max. Pressure: 150 psi
Max. Temperature: 250 °F
Max Speed: 100 RPM
Size: 3/4" - 1½"
# of passages:
1 - 2 |
|
Max. Pressure: 750 psi
Max. Temperature: 250 °F
Max Speed: 3500 RPM
Size: 1/4" - 2"
# of passages: 1 |
|
Max. Pressure: 5700 psi
Max. Temperature: 250 °F
Max Speed: 1500 RPM
Size: 1/4" - 1/2"
# of passages: 1 |
HIGH PRESSURE
LOW SPEED |
DOUBLE PASSAGE, HIGH PRESSURE, LOW SPEED |
FOUR PASSAGE, HIGH PRESSURE, LOW SPEED |
SIX PASSAGE, HIGH PRESSURE, LOW SPEED |
|
Max. Pressure: 150 psi
Max. Temperature: 250 °F
Max Speed: 250 RPM
Size: 3/8 " - 1/2"
# of passages: 1 |
|
Max. Pressure: 150 psi
Max. Temperature: 250 °F
Max Speed: 250 RPM
Size: 3/8"
# of passages: 2 |
|
Max. Pressure: 150 psi
Max. Temperature: 250 °F
Max Speed: 250 RPM
Size: 3/8 "
# of passages: 4 |
|
Max. Pressure: 150 psi
Max. Temperature: 250 °F
Max Speed: 250 RPM
Size: 3/8 "
# of passages: 6 |
ROTARY
JOINT
VAPOR
ROTARY
UNION
|
UNIVERSAL? |
? |
|
Max. Pressure: 120 psi
Max. Temperature: 330 °F
Max Speed: 500 RPM
Size: 1/4" - 2"
# of passages: 1 - 2 |
ROTARY
JOINT
HOT
OIL
ROTARY
UNION |
UNIVERSAL? |
? |
|
Max. Pressure: 100 psi
Max. Temperature: 395°F
Max Speed: 500 RPM
Size: 1/4" - 2"
# of passages: 1 - 2 |
ROTARY
JOINT
AIR
and
VAC-
UUM
ROTARY
UNION
|
AIR AND VACUUM |
IN THE SHAFT MOUNTING |
HIGH PRESSURE
LOW SPEED |
DOUBLE PASSAGE, HIGH PRESSURE, LOW SPEED |
|
Max. Pressure / Vacuum: 150 psi - 28"Hg
Max. Temperature: 250°F
Max Speed: 3500 RPM
Size: 1/4" - 2"
# of passages: 1 |
|
Max. Pressure / Vacuum: 150 psi - 28"Hg
Max. Temperature: 250°F
Max Speed: 3500 RPM
Size: 1/4" - 2"
# of passages: 1 |
|
Max. Pressure / Vacuum: 150 psi - 28"Hg
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8 - 1/2"
# of passages: 1 |
 |
Max. Pressure / Vacuum: 150 psi - 28"Hg
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8 "
# of passages: 1 |
FOUR PASSAGE, HIGH PRESSURE, LOW SPEED |
SIX PASSAGE, HIGH PRESSURE, LOW SPEED |
? |
|
Max. Pressure / Vacuum: 150 psi - 28"Hg
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8 "
# of passages: 4 |
|
Max. Pressure / Vacuum: 150 psi - 28"Hg
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8"
# of passages: 6 |
ROTARY
JOINT
OIL
ROTARY
UNION
|
HYDRAULIC OIL |
HIGH PRESSURE
HIGH SPEED |
IN THE SHAFT MOUNTING |
HIGH PRESSURE
LOW SPEED |
|
Max. Pressure: 750 psi
Max. Temperature: 250°F
Max Speed: 3500 RPM
Size: 1/4" - 2"
# of passages: 1 |
|
Max. Pressure: 5700 psi
Max. Temperature: 250°F
Max Speed: 1500 RPM
Size: 1/4" - 2"
# of passages: 1 |
 |
Max. Pressure: 750 psi
Max. Temperature: 250°F
Max Speed: 3500 RPM
Size: 1/4" - 2"
# of passages: 1 |
|
Max. Pressure: 850 - 3600 psi
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8" 1/2"
# of passages: 1 |
DOUBLE PASSAGE, HIGH PRESSURE, LOW SPEED |
4 PASSAGE, HIGH PRESSURE, LOW SPEED |
6 PASSAGE, HIGH PRESSURE, LOW SPEED |
???????????? |
|
Max. Pressure: 850 - 3600 psi
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8 "
# of passges: 2 |
|
Max. Pressure: 850 - 3600 psi
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8 "
# of passges: 4 |
|
Max. Pressure: 850 - 3600 psi
Max. Temperature: 250°F
Max Speed: 250 RPM
Size: 3/8 "
# of passges: 6 |
ROTARY
JOINT
COOL-
ANT
ROTARY
UNION
|
HIGH PRESSURE, HIGH SPEED |
HIGH PRESSURE, HIGH SPEED |
|
Max. Pressure: 600 - 1500 psi
Max. Temperature: 250°F
Max Speed: 10000 - 20000RPM
Size: 3/8 "
# of passges: 1 |
NOT FOR DRY RUNNING |
|
Max. Pressure: 600 - 1500 psi
Max. Temperature: 250°F
Max Speed: 10000 - 20000RPM
Size: 3/8 "
# of passges: 1 |
FOR DRY RUNNING |
